High Precision Roof Prism (Amici) for Image Erection and Beam Deviation

Precision Roof Prism (Amici Type)

The Precision Roof Prism (Amici Type) is a high-accuracy optical component engineered to deviate an incident beam by 90° while producing an erect, laterally correct image. It is specifically designed for applications requiring compact optical layouts without compromising image fidelity.

Manufactured from high-quality optical glass, the prism features a finely polished roof edge, where two reflective surfaces meet at a precise 90° angle. This geometry enables exact image erection and beam redirection, while maintaining excellent optical performance. Strict control over angular accuracy and roof edge sharpness ensures minimal image degradation and high contrast output.

Each prism is fabricated using advanced polishing techniques to achieve superior surface flatness, low wavefront distortion, and high dimensional precision, making it suitable for both standard and high-performance optical systems.

Key Optical Characteristics

• Beam deviation: 90°
• Image orientation: erect and laterally correct
• Roof angle accuracy: tightly controlled for minimal phase error
• High surface flatness for improved wavefront quality
• Low scattering and high transmission efficiency

Material & Coatings

• Optical Glass (e.g., BK7 or equivalent)
• Optional Anti-Reflection (AR) coatings
• Optional Phase-correction coatings for enhanced contrast
• Reflective coatings available as per application

Typical Specifications (Customizable)

• Surface Quality: up to 60/40 scratch-dig
• Surface Flatness: up to λ/4
• Angle Tolerance: 1arcmin
• Clear Aperture: >90% of face dimension

Applications

• Precision optical instruments
• Binocular and imaging systems
• Laser alignment and beam steering
• Surveying and metrology equipment
• Medical and laboratory optics

Manufacturing & Quality Assurance

At Azure Spy, each roof prism undergoes rigorous inspection for:

• Angular accuracy
• Surface quality
• Optical performance
